Задължителен е минимум 3-годишен лиценз DNA Advantage!
Спецификации
- Суич, типModular
- Общ брой портове48
- Основни портове, тип48x 10G Multigigabit (10G/5G/2.5G/1G/100M), Data ports
- Power Over Ethernet (PoE)-
- Uplink портовеModular Uplinks
- Свободни (10GB) слотове-
- УправлениеCloud management and monitoring; WebUI
- StackableDesigned for stacking switches as a single virtual switch, enabling customers to have a single management plane and control plane for up to 448 access ports.
- FansThree field-replaceable fans and support (N+1) redundancy.
- ЗахранванеRedundant; Default AC power supply: 715W AC
- RoutingHigh-Performance IP routing; Total routed ports: 448
- Памет (Flash, RAM)DRAM: 8 GB; Flash: 16 GB; Packet buffer per SKU: 16 MB buffer for 24-or 48-port Gigabit Ethernet models
- Капацитет за маршрутизиране/превключване, Gbps1760 Gbps, Switching capacity with stacking: 2760 Gbps
- Пропускателна способност, Mpps1309 Mpps; Forwarding rate with stacking: 2232 Mpps
- MAC адреси32 000
- VLAN (брой, стандарти)VLAN IDs: 4094; IEEE 802.1Q VLAN
- QoSQoS scale entries: 5 120; Superior QoS (802.1p Class of Service (CoS), DSCP, SRR, CIR)
- L2 мрежови стандартиIEEE 802.3 ab/z/bz/an/x
- L3 мрежови стандартиIEEE 802.1D, RMON I and II standards, SNMPv1, v2c, and v3
- IPv6 functionalityIPv6 routing entries: 16 000
- СигурностETA, SUDI, AES-256 MACsec encryption, IPsec encryption, Trustworthy solutions built with Cisco Trust Anchor Technologies; Cloud Security: Umbrella DNS Integration, ASAc
- Размери (Ш, Д, В), mm445 x 483 x 44 mm
- Опция за монтажRackmount
- Гаранция, м.99 месеца
- Тегло, кг.8 кг.
- ДругиNetwork Essentials
