Задължителен е минимум 3-годишен лиценз DNA Advantage!

Спецификации

Суич, тип
Modular
Общ брой портове
48
Основни портове, тип
10/100/1000Base-T
Power Over Ethernet (PoE)
Cisco UPOE+ (90W per port) & IEEE 802.3bt type4 on 21 ports (24-port and 48-port switch)
Uplink портове
Modular Uplinks
Свободни (10GB) слотове
-
Управление
Cloud management and monitoring; WebUI
Stackable
Designed for stacking switches as a single virtual switch, enabling customers to have a single management plane and control plane for up to 448 access ports.
Fans
Three field-replaceable fans and support (N+1) redundancy.
Захранване
Redundant; Default AC power supply: 1100W AC
Routing
High-Performance IP routing; Total routed ports: 448
Памет (Flash, RAM)
DRAM: 8 GB; Flash: 16 GB; Packet buffer per SKU: 16 MB buffer for 24-or 48-port Gigabit Ethernet models
Капацитет за маршрутизиране/превключване, Gbps
256 Gbps, Switching capacity with stacking: 736 Gbps
Пропускателна способност, Mpps
190.48 Mpps; Forwarding rate with stacking: 547.62 Mpps
MAC адреси
32 000
VLAN (брой, стандарти)
VLAN IDs: 4094; IEEE 802.1Q VLAN
QoS
QoS scale entries: 5 120; Superior QoS (802.1p Class of Service (CoS), DSCP, SRR, CIR)
L2 мрежови стандарти
IEEE 802.3 ab/z/bz/an/x
L3 мрежови стандарти
IEEE 802.1D, RMON I and II standards, SNMPv1, v2c, and v3
IPv6 functionality
IPv6 routing entries: 16 000
Сигурност
ETA, SUDI, AES-256 MACsec encryption, IPsec encryption, Trustworthy solutions built with Cisco Trust Anchor Technologies; Cloud Security: Umbrella DNS Integration, ASAc
Размери (Ш, Д, В), mm
445 x 409 x 44 mm
Опция за монтаж
Rackmount
Гаранция, м.
99 месеца
Тегло, кг.
8.5 кг.
Други
Network Essentials
